Relativity keeps track of overturned documents - documents whose responsiveness status is overturned either on a second pass manual review, or by a manual coding decision made before an assisted review or TAR round is performed. Subsequent rounds of assisted review may lead to overturned documents.


A document reviewer may see a field for a responsive overturn on a document layout.



The Assisted Review console includes options to 'View Overturn Summary' and 'View Overturned Documents'.



Relativity keeps track of which reviewer gave a different value to a document, his or her coding value, and associates the document with the seed document or seed excerpt responsible for the overturn. A field named 'Overturned category rank' shows the degree of similarity between the seed document and the overturned document.




Relativity can use only excerpted text from a document to find conceptual matches to a control document.








The Tip of the Night for May 20, 2020, discussed how to use Visual Basic code to remove the protection for a worksheet in Excel. This night's tip demonstrates alternate vba code to edit protection placed on an Excel workbook.


This code successfully removed the protection for a worksheet protected with a fairly strong password: GiraffeY2K2020 - in just a few seconds.


1. Open a blank Excel workbook, and as always press ALT + F11 to open Visual Basic. Insert the below code in a new module in the project list on the left.


2. Press play to run the macro. You will be prompted to select the Excel file to process.


3. The macro will create a copy of the file in its original directory and append the date and current time to the end of the file.


When the processing is done, any restrictions on the file should be removed. As the below screen grab shows, the macro works quite rapidly.





See the version of the code posted here, by Excel Off the Grid.


Sub RemoveProtection()


Dim dialogBox As FileDialog

Dim sourceFullName As String

Dim sourceFilePath As String

Dim sourceFileName As String

Dim sourceFileType As String

Dim newFileName As Variant

Dim tempFileName As String

Dim zipFilePath As Variant

Dim oApp As Object

Dim FSO As Object

Dim xmlSheetFile As String

Dim xmlFile As Integer

Dim xmlFileContent As String

Dim xmlStartProtectionCode As Double

Dim xmlEndProtectionCode As Double

Dim xmlProtectionString As String


'Open dialog box to select a file

Set dialogBox = Application.FileDialog(msoFileDialogFilePicker)

dialogBox.AllowMultiSelect = False

dialogBox.Title = "Select file to remove protection from"


If dialogBox.Show = -1 Then

sourceFullName = dialogBox.SelectedItems(1)

Else

Exit Sub

End If


'Get folder path, file type and file name from the sourceFullName

sourceFilePath = Left(sourceFullName, InStrRev(sourceFullName, "\"))

sourceFileType = Mid(sourceFullName, InStrRev(sourceFullName, ".") + 1)

sourceFileName = Mid(sourceFullName, Len(sourceFilePath) + 1)

sourceFileName = Left(sourceFileName, InStrRev(sourceFileName, ".") - 1)


'Use the date and time to create a unique file name

tempFileName = "Temp" & Format(Now, " dd-mmm-yy h-mm-ss")


'Copy and rename original file to a zip file with a unique name

newFileName = sourceFilePath & tempFileName & ".zip"

On Error Resume Next

FileCopy sourceFullName, newFileName


If Err.Number <> 0 Then

MsgBox "Unable to copy " & sourceFullName & vbNewLine _

& "Check the file is closed and try again"

Exit Sub

End If

On Error GoTo 0


'Create folder to unzip to

zipFilePath = sourceFilePath & tempFileName & "\"

MkDir zipFilePath


'Extract the files into the newly created folder

Set oApp = CreateObject("Shell.Application")

oApp.Namespace(zipFilePath).CopyHere oApp.Namespace(newFileName).items


'loop through each file in the \xl\worksheets folder of the unzipped file

xmlSheetFile = Dir(zipFilePath & "\xl\worksheets\*.xml*")

Do While xmlSheetFile <> ""


'Read text of the file to a variable

xmlFile = FreeFile

Open zipFilePath & "xl\worksheets\" & xmlSheetFile For Input As xmlFile

xmlFileContent = Input(LOF(xmlFile), xmlFile)

Close xmlFile


'Manipulate the text in the file

xmlStartProtectionCode = 0

xmlStartProtectionCode = InStr(1, xmlFileContent, "<sheetProtection")


If xmlStartProtectionCode > 0 Then


xmlEndProtectionCode = InStr(xmlStartProtectionCode, _

xmlFileContent, "/>") + 2 '"/>" is 2 characters long

xmlProtectionString = Mid(xmlFileContent, xmlStartProtectionCode, _

xmlEndProtectionCode - xmlStartProtectionCode)

xmlFileContent = Replace(xmlFileContent, xmlProtectionString, "")


End If


'Output the text of the variable to the file

xmlFile = FreeFile

Open zipFilePath & "xl\worksheets\" & xmlSheetFile For Output As xmlFile

Print #xmlFile, xmlFileContent

Close xmlFile


'Loop to next xmlFile in directory

xmlSheetFile = Dir


Loop


'Read text of the xl\workbook.xml file to a variable

xmlFile = FreeFile

Open zipFilePath & "xl\workbook.xml" For Input As xmlFile

xmlFileContent = Input(LOF(xmlFile), xmlFile)

Close xmlFile


'Manipulate the text in the file to remove the workbook protection

xmlStartProtectionCode = 0

xmlStartProtectionCode = InStr(1, xmlFileContent, "<workbookProtection")

If xmlStartProtectionCode > 0 Then


xmlEndProtectionCode = InStr(xmlStartProtectionCode, _

xmlFileContent, "/>") + 2 ''"/>" is 2 characters long

xmlProtectionString = Mid(xmlFileContent, xmlStartProtectionCode, _

xmlEndProtectionCode - xmlStartProtectionCode)

xmlFileContent = Replace(xmlFileContent, xmlProtectionString, "")


End If


'Manipulate the text in the file to remove the modify password

xmlStartProtectionCode = 0

xmlStartProtectionCode = InStr(1, xmlFileContent, "<fileSharing")

If xmlStartProtectionCode > 0 Then


xmlEndProtectionCode = InStr(xmlStartProtectionCode, xmlFileContent, _

"/>") + 2 ''"/>" is 2 characters long

xmlProtectionString = Mid(xmlFileContent, xmlStartProtectionCode, _

xmlEndProtectionCode - xmlStartProtectionCode)

xmlFileContent = Replace(xmlFileContent, xmlProtectionString, "")


End If


'Output the text of the variable to the file

xmlFile = FreeFile

Open zipFilePath & "xl\workbook.xml" & xmlSheetFile For Output As xmlFile

Print #xmlFile, xmlFileContent

Close xmlFile


'Create empty Zip File

Open sourceFilePath & tempFileName & ".zip" For Output As #1

Print #1, Chr$(80) & Chr$(75) & Chr$(5) & Chr$(6) & String(18, 0)

Close #1


'Move files into the zip file

oApp.Namespace(sourceFilePath & tempFileName & ".zip").CopyHere _

oApp.Namespace(zipFilePath).items

'Keep script waiting until Compressing is done

On Error Resume Next

Do Until oApp.Namespace(sourceFilePath & tempFileName & ".zip").items.Count = _

oApp.Namespace(zipFilePath).items.Count

Application.Wait (Now + TimeValue("0:00:01"))

Loop

On Error GoTo 0


'Delete the files & folders created during the sub

Set FSO = CreateObject("scripting.filesystemobject")

FSO.deletefolder sourceFilePath & tempFileName


'Rename the final file back to an xlsx file

Name sourceFilePath & tempFileName & ".zip" As sourceFilePath & sourceFileName _

& "_" & Format(Now, "dd-mmm-yy h-mm-ss") & "." & sourceFileType


'Show message box

MsgBox "The workbook and worksheet protection passwords have been removed.", _

vbInformation + vbOKOnly, Title:="Password protection"


End Sub

RelativityOne uses IBM's Aspera file transfer software to move data more quickly than is possible with common FTP software. The rates can be as high as 10 times as fast. Relativity Desktop Client includes an Aspera mode, and RelativityOne Staging Explorer can import data for a workspace configured for Aspera to a staging area and export data from RelativityOne workspaces.




You can find out how quickly your workstation can upload data with Aspera by using the IBM Aspera File Transfer Calculator. As you can see, considerable can be saved over transfer speeds with standard TCP (Transmission Control Protocol - still the most widely used protocol for internet communications).



. . . although admittedly these totals are only for my personal laptop.
