Excel Macro to List Ranges on All Worksheets

Excel Macro to List Ranges on All Worksheets

December 13, 2016

If you've got a spreadsheet with a large number of worksheets, and you want to run a formula from one an all of them, but aren't sure of the respective data ranges on each, try this macro posted to the Contextures Blog of Debra Dalgleish.



So as we can see in this example we have three worksheets which each contain different ranges of data.  Some of the ranges have blank cells within them.









Entering Visual Basic (ALT + F11) and inserting the below code into a module with set up the macro.  When you run it, a new worksheet will be created showing the full ranges on each worksheet.







Sub ListSheetsRangeInfo()
Dim ws As Worksheet
Dim lCount As Long
Dim wsTemp As Worksheet
Dim rngF As Range
Dim lFields As Long
Dim strLC As String
Dim strSh As String
Dim sh As Shape
Application.EnableEvents = False
Application.ScreenUpdating = False
On Error Resume Next

  Set wsTemp = Worksheets _
      .Add(Before:=Sheets(1))
  lCount = 2
  lFields = 5

  With wsTemp
    .Range(.Cells(1, 1), _
      .Cells(1, lFields)).Value _
          = Array( _
              "Sheet Name", _
              "Used Range", _
              "Range Cells", _
              "Shapes", _
              "Last Cell")
  End With

  For Each ws In ActiveWorkbook.Worksheets
    If ws.Name <> wsTemp.Name Then
      strSh = ""
      strLC = ws.Cells _
        .SpecialCells(xlCellTypeLastCell) _
          .Address
      If ws.Shapes.Count > 0 Then
        For Each sh In ws.Shapes
          strSh = strSh & sh.TopLeftCell _
              .Address & ", "
        Next sh
        strSh = Left(strSh, Len(strSh) - 2)
      End If

      With wsTemp
        .Range(.Cells(lCount, 1), _
          .Cells(lCount, lFields)).Value _
          = Array( _
              ws.Name, _
              ws.UsedRange.Address, _
              ws.UsedRange.Cells.Count, _
              strSh, _
              strLC)
        'add hyperlink to sheet name
        .Hyperlinks.Add _
            Anchor:=.Cells(lCount, 1), _
            Address:="", _
            SubAddress:="'" & ws.Name _
                & "'!A1", _
            ScreenTip:=ws.Name, _
            TextToDisplay:=ws.Name
        'add hyperlink to last cell
        .Hyperlinks.Add _
            Anchor:=.Cells(lCount, lFields), _
            Address:="", _
            SubAddress:="'" & ws.Name _
                & "'!" & strLC, _
            ScreenTip:=strLC, _
            TextToDisplay:=strLC

        lCount = lCount + 1
      End With
    End If
  Next ws

With wsTemp
    .Range(.Cells(1, 1), .Cells(1, lFields)) _
      .EntireColumn.AutoFit
    .Rows(1).Font.Bold = True
End With

Application.EnableEvents = True
Application.ScreenUpdating = True

End Sub
